Writing flat files in Java with Flatworm

I previously wrote about how to parse and read flat files in Java using Flatworm. In this post, I'll show you how you can write flat files with Flatworm. The benefit to using the Flatworm library for flat file creation is that you can use the exact same file descriptor document you use to parse a particular format. The developer doesn't have to concern themselves with the details of the file layout and can focus on the data going into the file. Writing Using Our Previous Example Let's revisit the sample data format we used when we explored how to parse and read flat files with Flatworm.

Name	Start	End	Length	Type
Type	1	2	2	Char
First	3	27	25	Char
Middle	28	52	25	Char
Last	53	77	25	Char
Acct. ID	78	92	15	Char

Below is the sample flat file we will be writing.

CDJOHN                     MARK                     DOE                      111111111111111
CDPAUL                     RICHARD                  STEPHENS                 222222222222222
CDRINGO                    JACK                     ERICSON                  333333333333333

Now that we know the file format of our flat file and we have some sample data to parse we'll need to create an XML document describing our file format for Flatworm.

<?xml version="1.0" encoding="ISO-8859-1"?>
<!--<!DOCTYPE file-format SYSTEM "http://www.blackbear.com/dtds/flatworm-data-description_1_0.dtd">-->
<file-format>
    <converter name="char" class="com.blackbear.flatworm.converters.CoreConverters" method="convertChar" return-type="java.lang.String"/>
    <record name="clientData">
        <record-ident>
            <field-ident field-start="0" field-length="2">
                <match-string>CD</match-string>
            </field-ident>
        </record-ident>
        <record-definition>
            <bean name="client" class="org.javaconfessions.sample.Client"/>
            <line>
                <record-element length="2"/>
                <record-element length="25" beanref="client.firstName" type="char">
                    <conversion-option name="justify" value="left"/>
                    <conversion-option name="pad-character" value=" "/>
                </record-element>
                <record-element length="25" beanref="client.middleName" type="char">
                    <conversion-option name="justify" value="left"/>
                </record-element>
                <record-element length="25" beanref="client.lastName" type="char">
                    <conversion-option name="justify" value="left"/>
                </record-element>
                <record-element length="15" beanref="client.accountId" type="char">
                    <conversion-option name="justify" value="left"/>
                </record-element>
            </line>
        </record-definition>
    </record>
</file-format>

Closer Look at the Descriptor File Looking further at the XML descriptor file, you can see it is rather simple to describe our file format for Flatworm. The record tag is the beginning of describing our client data records. Within the record tag, we have our record-ident tag. This is so Flatworm knows how to identify the types of records in a flat file. Most flat file formats have different types of records including header, footer, detail, batch headers, batch footers, etc. This mechanism allows Flatworm to parse out all of these different record types from the same file. The field-ident tag gives the specifics on how to identify the record. Field-start and field-length identifies what to test to identify the record type. Within the match-string tags is where the text that would be used to identify this record as a clientData record. In the descriptor above, we have described clientData records as starting with the characters CD. The next section of the record description is the record-definition tag. This is where we actually map out each record element to a bean property for Flatworm. This section of the document starts with a bean definition that tells Flatworm which Java class to use when parsing this record type. The record-element tags setup where each field in the record is located, the data type, and where to plug it into the Java bean during parsing. Here is the source code for my Client bean.

package org.javaconfessions.sample;

public class Client {

   private String firstName;
   private String middleName;
   private String lastName;
   private String accountId;

   public String getFirstName() {
       return firstName;
   }

   public void setFirstName(String pFirstName) {
       firstName = pFirstName;
   }

   public String getMiddleName() {
       return middleName;
   }

   public void setMiddleName(String pMiddleName) {
       middleName = pMiddleName;
   }

   public String getLastName() {
       return lastName;
   }

   public void setLastName(String pLastName) {
       lastName = pLastName;
   }

   public String getAccountId() {
       return accountId;
   }

   public void setAccountId(String pAccountId) {
       accountId = pAccountId;
   }

   @Override
   public String toString() {
       return "First Name: " + firstName + "\nMiddleName: " + middleName
               + "\nLastName: " + lastName + "\nAccount ID: " + accountId
               + "\n";
   }

}

Now that we have described the data model for our project, below is a sample class that populates a couple of Client beans and then has Flatworm write out the data in our specified file format.

package org.javaconfessions.sample;

import com.blackbear.flatworm.FileCreator;

public class ClientDataWriter {

   public static void main(String[] args) {
       FileCreator fileCreator = null;
       try {
           fileCreator = new FileCreator(args[0], args[1]);
           fileCreator.open();
           fileCreator.setRecordSeperator("\n");
           Client client = new Client();
           fileCreator.setBean("client", client);
           client.setFirstName("JOHN");
           client.setMiddleName("MARK");
           client.setLastName("DOE");
           client.setAccountId("111111111111111");
           fileCreator.write("clientData");
           client.setFirstName("PAUL");
           client.setMiddleName("RICHARD");
           client.setLastName("STEPHENS");
           client.setAccountId("222222222222222");
           fileCreator.write("clientData");
           client.setFirstName("RINGO");
           client.setMiddleName("JACK");
           client.setLastName("ERICSON");
           client.setAccountId("333333333333333");
           fileCreator.write("clientData");
       } catch (Exception e) {
           e.printStackTrace();
       } finally {
           try{
               fileCreator.close();
           } catch( Exception e ) {
               e.printStackTrace();
           }
       }
   }
}

A Closer Look at ClientDataWriter.java Looking at the sample code above, we can see that first we are creating a FileCreator object using parameters passed in. The first parameter given is the path to our Descriptor XML Document and the second parameter will be the location where the data file should be written. Next we call the open() method on the FileCreator object to open our file. The next call sets the record separator for our data file which in this case is a new line. After getting our FileCreator object setup, we instantiate a Client bean. After instantiating our Client bean, we call setBean() on the FileCreator to tell the FileCreator about our Client bean and what type of bean it is. Notice that "client" is the name of our bean in the descriptor file. The next part is pretty self explanatory, we setup our first client record, then call fileCreator.write() passing in the type of record we want to write, in this case a "clientData" record. Then we repeat for the second and third records. After writing out the records, we call the close() method on the FileCreator to close out the data file. Gotcha The Flatworm FileCreator will always put the record identifiers at the beginning of the record in the flat file. This doesn't always work because sometimes, you may have a situation where the record identifier in the middle of the record. I have a patch for the FileCreator below if you want to change this in the source. If you apply this patch, you will need to setup the record identifier portion of the bean description with the default values, in our case here "CD". However, you will have to do this for all constant data types in your file format that aren't specified in your bean or your file format will be incorrect.

Index: src/com/blackbear/flatworm/FileCreator.java
--- src/com/blackbear/flatworm/FileCreator.java Base (1.3)
+++ src/com/blackbear/flatworm/FileCreator.java Locally Modified (Based On 1.3)
@@ -212,12 +212,12 @@
// record-ident contain what is considered hard-coded data
// for the output line, these can be used to uniquely identify
// lines for parsers. We need to write them out.
- Vector recIdents = record.getFieldIdentMatchStrings();
+ /*Vector recIdents = record.getFieldIdentMatchStrings();
for (Iterator itRecIdents = recIdents.iterator(); itRecIdents.hasNext();)
{
String id = (String) itRecIdents.next();
bufOut.write(id + delimit);
- }
+ }*/

// Iterate over record-element items
Vector recElements = line.getRecordElements();
